前言
websocket 使得客户端和服务器之间的数据交换变得更加简单，允许服务端主动向客户端推送数据。在 websocket api 中，浏览器和服务器只需要完成一次握手，两者之间就直接可以创建持久性的连接，并进行双向数据传输。
netty框架的优势
1. api使用简单，开发门槛低；
2. 功能强大，预置了多种编解码功能，支持多种主流协议；
3. 定制能力强，可以通过channelhandler对通信框架进行灵活地扩展；
4. 性能高，通过与其他业界主流的nio框架对比，netty的综合性能最优；
5. 成熟、稳定，netty修复了已经发现的所有jdk nio bug，业务开发人员不需要再为nio的bug而烦恼
提示：以下是本篇文章正文内容，下面案例可供参考
一、引入netty依赖
<dependency> <groupid>io.netty</groupid> <artifactid>netty-all</artifactid> <version>4.1.48.final</version> </dependency>
二、使用步骤
1.引入基础配置类
package com.test.netty;
public enum cmd {
start("000", "连接成功"),
wmessage("001", "消息提醒"),
;
private string cmd;
private string desc;
cmd(string cmd, string desc) {
this.cmd = cmd;
this.desc = desc;
}
public string getcmd() {
return cmd;
}
public string getdesc() {
return desc;
}
}
2.netty服务启动监听器
package com.test.netty;
import io.netty.bootstrap.serverbootstrap;
import io.netty.channel.channelfuture;
import io.netty.channel.channeloption;
import io.netty.channel.eventloopgroup;
import io.netty.channel.nio.nioeventloopgroup;
import io.netty.channel.socket.nio.nioserversocketchannel;
import lombok.extern.slf4j.slf4j;
import org.springframework.beans.factory.annotation.autowired;
import org.springframework.beans.factory.annotation.value;
import org.springframework.boot.applicationrunner;
import org.springframework.context.annotation.bean;
import org.springframework.stereotype.component;
/**
* @author test
* <p>
* 服务启动监听器
**/
@slf4j
@component
public class nettyserver {
@value("${server.netty.port}")
private int port;
@autowired
private serverchannelinitializer serverchannelinitializer;
@bean
applicationrunner nettyrunner() {
return args -> {
//new 一个主线程组
eventloopgroup bossgroup = new nioeventloopgroup(1);
//new 一个工作线程组
eventloopgroup workgroup = new nioeventloopgroup();
serverbootstrap bootstrap = new serverbootstrap()
.group(bossgroup, workgroup)
.channel(nioserversocketchannel.class)
.childhandler(serverchannelinitializer)
//设置队列大小
.option(channeloption.so_backlog, 1024)
// 两小时内没有数据的通信时,tcp会自动发送一个活动探测数据报文
.childoption(channeloption.so_keepalive, true);
//绑定端口,开始接收进来的连接
try {
channelfuture future = bootstrap.bind(port).sync();
log.info("服务器启动开始监听端口: {}", port);
future.channel().closefuture().sync();
} catch (interruptedexception e) {
e.printstacktrace();
} finally {
//关闭主线程组
bossgroup.shutdowngracefully();
//关闭工作线程组
workgroup.shutdowngracefully();
}
};
}
}
3.netty服务端处理器
package com.test.netty;
import com.test.common.util.jsonutil;
import io.netty.channel.channel;
import io.netty.channel.channelhandler;
import io.netty.channel.channelhandlercontext;
import io.netty.channel.simplechannelinboundhandler;
import io.netty.handler.codec.http.websocketx.textwebsocketframe;
import io.netty.handler.codec.http.websocketx.websocketserverprotocolhandler;
import lombok.data;
import lombok.extern.slf4j.slf4j;
import org.springframework.beans.factory.annotation.autowired;
import org.springframework.stereotype.component;
import java.net.urldecoder;
import java.util.*;
/**
* @author test
* <p>
* netty服务端处理器
**/
@slf4j
@component
@channelhandler.sharable
public class nettyserverhandler extends simplechannelinboundhandler<textwebsocketframe> {
@autowired
private serverchannelcache cache;
private static final string datakey = "test=";
@data
public static class channelcache {
}
/**
* 客户端连接会触发
*/
@override
public void channelactive(channelhandlercontext ctx) throws exception {
channel channel = ctx.channel();
log.info("通道连接已打开，id->{}......", channel.id().aslongtext());
}
@override
public void usereventtriggered(channelhandlercontext ctx, object evt) throws exception {
if (evt instanceof websocketserverprotocolhandler.handshakecomplete) {
channel channel = ctx.channel();
websocketserverprotocolhandler.handshakecomplete handshakecomplete = (websocketserverprotocolhandler.handshakecomplete) evt;
string requesturi = handshakecomplete.requesturi();
requesturi = urldecoder.decode(requesturi, "utf-8");
log.info("handshake_complete，id->{}，uri->{}", channel.id().aslongtext(), requesturi);
string socketkey = requesturi.substring(requesturi.lastindexof(datakey) + datakey.length());
if (socketkey.length() > 0) {
cache.add(socketkey, channel);
this.send(channel, cmd.down_start, null);
} else {
channel.disconnect();
ctx.close();
}
}
super.usereventtriggered(ctx, evt);
}
@override
public void channelinactive(channelhandlercontext ctx) throws exception {
channel channel = ctx.channel();
log.info("通道连接已断开，id->{}，用户id->{}......", channel.id().aslongtext(), cache.getcacheid(channel));
cache.remove(channel);
}
/**
* 发生异常触发
*/
@override
public void exceptioncaught(channelhandlercontext ctx, throwable cause) throws exception {
channel channel = ctx.channel();
log.error("连接出现异常，id->{}，用户id->{}，异常->{}......", channel.id().aslongtext(), cache.getcacheid(channel), cause.getmessage(), cause);
cache.remove(channel);
ctx.close();
}
/**
* 客户端发消息会触发
*/
@override
protected void channelread0(channelhandlercontext ctx, textwebsocketframe msg) throws exception {
try {
// log.info("接收到客户端发送的消息：{}", msg.text());
ctx.channel().writeandflush(new textwebsocketframe(jsonutil.tostring(collections.singletonmap("cmd", "100"))));
} catch (exception e) {
log.error("消息处理异常：{}", e.getmessage(), e);
}
}
public void send(cmd cmd, string id, object obj) {
hashmap<string, channel> channels = cache.get(id);
if (channels == null) {
return;
}
map<string, object> data = new linkedhashmap<>();
data.put("cmd", cmd.getcmd());
data.put("data", obj);
string msg = jsonutil.tostring(data);
log.info("服务器下发消息: {}", msg);
channels.values().foreach(channel -> {
channel.writeandflush(new textwebsocketframe(msg));
});
}
public void send(channel channel, cmd cmd, object obj) {
map<string, object> data = new linkedhashmap<>();
data.put("cmd", cmd.getcmd());
data.put("data", obj);
string msg = jsonutil.tostring(data);
log.info("服务器下发消息: {}", msg);
channel.writeandflush(new textwebsocketframe(msg));
}
}
4.netty服务端缓存类
package com.test.netty;
import io.netty.channel.channel;
import io.netty.util.attributekey;
import org.springframework.stereotype.component;
import java.util.hashmap;
import java.util.concurrent.concurrenthashmap;
@component
public class serverchannelcache {
private static final concurrenthashmap<string, hashmap<string, channel>> cache_map = new concurrenthashmap<>();
private static final attributekey<string> channel_attr_key = attributekey.valueof("test");
public string getcacheid(channel channel) {
return channel.attr(channel_attr_key).get();
}
public void add(string cacheid, channel channel) {
channel.attr(channel_attr_key).set(cacheid);
hashmap<string, channel> hashmap = cache_map.get(cacheid);
if (hashmap == null) {
hashmap = new hashmap<>();
}
hashmap.put(channel.id().asshorttext(), channel);
cache_map.put(cacheid, hashmap);
}
public hashmap<string, channel> get(string cacheid) {
if (cacheid == null) {
return null;
}
return cache_map.get(cacheid);
}
public void remove(channel channel) {
string cacheid = getcacheid(channel);
if (cacheid == null) {
return;
}
hashmap<string, channel> hashmap = cache_map.get(cacheid);
if (hashmap == null) {
hashmap = new hashmap<>();
}
hashmap.remove(channel.id().asshorttext());
cache_map.put(cacheid, hashmap);
}
}
5.netty服务初始化器
package com.test.netty;
import io.netty.channel.channelinitializer;
import io.netty.channel.channelpipeline;
import io.netty.channel.socket.socketchannel;
import io.netty.handler.codec.http.httpobjectaggregator;
import io.netty.handler.codec.http.httpservercodec;
import io.netty.handler.codec.http.websocketx.websocketserverprotocolhandler;
import io.netty.handler.stream.chunkedwritehandler;
import org.springframework.beans.factory.annotation.autowired;
import org.springframework.stereotype.component;
/**
* @author test
* <p>
* netty服务初始化器
**/
@component
public class serverchannelinitializer extends channelinitializer<socketchannel> {
@autowired
private nettyserverhandler nettyserverhandler;
@override
protected void initchannel(socketchannel socketchannel) throws exception {
channelpipeline pipeline = socketchannel.pipeline();
pipeline.addlast(new httpservercodec());
pipeline.addlast(new chunkedwritehandler());
pipeline.addlast(new httpobjectaggregator(8192));
pipeline.addlast(new websocketserverprotocolhandler("/test.io", true, 5000));
pipeline.addlast(nettyserverhandler);
}
}
6.html测试
<!doctype html>
<html>
<head>
<meta charset="utf-8">
<title>test</title>
<script type="text/javascript">
function websockettest()
{
if ("websocket" in window)
{
alert("您的浏览器支持 websocket!");
// 打开一个 web socket
var ws = new websocket("ws://localhost:port/test.io");
ws.onopen = function()
{
// web socket 已连接上，使用 send() 方法发送数据
ws.send("发送数据");
alert("数据发送中...");
};
ws.onmessage = function (evt)
{
var received_msg = evt.data;
alert("数据已接收...");
};
ws.onclose = function()
{
// 关闭 websocket
alert("连接已关闭...");
};
}
else
{
// 浏览器不支持 websocket
alert("您的浏览器不支持 websocket!");
}
}
</script>
</head>
<body>
<div id="sse">
<a href="javascript:websockettest()" rel="external nofollow" >运行 websocket</a>
</div>
</body>
</html>
7.vue测试
mounted() {
this.initwebsocket();
},
methods: {
initwebsocket() {
let websocket = new websocket('ws://localhost:port/test.io?test=123456');
websocket.onmessage = (event) => {
let msg = json.parse(event.data);
switch (msg.cmd) {
case "000":
this.$message({
type: 'success',
message: "建立实时连接成功！",
duration: 1000
})
setinterval(()=>{websocket.send("heartbeat")},60*1000);
break;
case "001":
this.$message.warning("收到一条新的信息，请及时查看！")
break;
}
}
websocket.onclose = () => {
settimeout(()=>{
this.initwebsocket();
},30*1000);
}
websocket.onerror = () => {
settimeout(()=>{
this.initwebsocket();
},30*1000);
}
},
},
8.服务器下发消息
@autowired private nettyserverhandler nettyserverhandler; nettyserverhandler.send(cmdweb.wmessage, id, message);
